UHMWPE High Strength 12-Strand
APPLICATIONS
FEATURES
APPLICATIONS
FEATURES
ROPE SIZE DIAMETER | STOCK NUMBER | DESCRIPTION | REEL LENGTH | COLOR | WORKING LOAD LIMIT (lbs.) | MINIMUM BREAKING STRENGTH (lbs.) |
---|---|---|---|---|---|---|
1/4” | UHM250 | UHMWPE 12 Strand Rope | 600′ | Purple | 1,600 | 8,000 |
3/8” | UHM375 | UHMWPE 12 Strand Rope | 600′ | Purple | 3,500 | 17,500 |
1/2” | UHM500 | UHMWPE 12 Strand Rope | 600′ | Purple | 6,200 | 31,000 |
5/8” | UHM625 | UHMWPE 12 Strand Rope | 600′ | Purple | 10,200 | 51,000 |
3/4” | UHM750 | UHMWPE 12 Strand Rope | 600′ | Purple | 13,700 | 68,500 |
7/8” | UHM875 | UHMWPE 12 Strand Rope | 600′ | Purple | 18,500 | 92,500 |
1” | UHM100 | UHMWPE 12 Strand Rope | 600′ | Purple | 22,000 | 110,000 |
1-1/8” | UHM1125 | UHMWPE 12 Strand Rope | 600′ | Purple | 29,400 | 147,000 |
1-1/4” | UHM1250 | UHMWPE 12 Strand Rope | 600′ | Purple | 33,000 | 165,000 |
1-1/2” | UHM1500 | UHMWPE 12 Strand Rope | 600′ | Purple | 44,200 | 221,000 |
1-3/4” | UHM1750 | UHMWPE 12 Strand Rope | 600′ | Purple | 62,000 | 310,000 |
2” | UHM200 | UHMWPE 12 Strand Rope | 600′ | Purple | 71,000 | 355,000 |
Tensile Strengths are determined in accordance with Cordage Institute 1500.2.
ROPE SIZE DIAMETER |
WORKING LOAD LIMIT (lbs.) | ||
---|---|---|---|
VERTICAL |
CHOKER |
BASKET |
|
1/4” | 1,600 | 1,200 | 3,200 |
3/8” | 3,500 | 2,800 | 7,000 |
1/2” | 6,200 | 5,000 | 12,400 |
5/8” | 10,200 | 8,200 | 20,400 |
3/4” | 13,700 | 10,900 | 27,400 |
7/8” | 18,500 | 14,800 | 37,000 |
1” | 22,000 | 17,600 | 44,000 |
1-1/8” | 29,400 | 23,500 | 58,800 |
1-1/4” | 33,000 | 26,400 | 66,000 |
1-1/2” | 44,200 | 35,300 | 88,400 |
1-3/4” | 62,000 | 50,000 | 124,000 |
2” | 71,000 | 56,000 | 142,000 |
Features & Benefits
Applications
